Tektronix AFG1022 User Manual

Operating basics
34
AFG1000 Series Quick Start User Manual
Generate noise
1. Push the front-panel
Noise
waveform
button.
2. Use the general
purpose knob or the
numeric keypad to
adjust Ampl, High,
Offset and Low.
NOTE: You cannot modulate, sweep, or burst a noise waveform.
Generate DC
1. Push the front-panel
Arb button.
2. Press Others.
3. Press Built-in.
4. Press Others.
5. Select DC, press Select
to output a DC waveform.
NOTE: You cannot modulate, sweep, or burst a DC waveform.
