Tektronix AFG1062 Technical Reference

AFG1000 Series Specifications and Performance Verification
3
Specifications
These specifications apply to the AFG1000 Series Arbitrary Function Generator.
All
specifications are guaranteed unless labeled "typical". Typical specifications
are
provided for your convenience but are not guaranteed.
Specifications that are check marked with the
symbol are checked directly (or
indirectly) in the Performance tests section.
All specifications apply to the arbitrary function generator unless noted otherwise.
These specifications are valid under the following conditions:
The instrument must have been calibrated/adjusted at an ambient temperature
between +20 °C and +30 °C.
The instrument must be operating at an ambient temperature between 0 °C
and +40 °C.
The instrument must have had a warm-up period of at least 30 minutes.
The instrument must be in an environment with temperature, altitude and
humidity within the operating limits described in these specifications.
Electrical specifications
Table 2: Operating mode
Characteristic Description
Run mode Continuous, Modulation, Sweep, and Burst
Table 3: Waveforms
Characteristic Description
Standard Sine, Square, Ramp, Pulse, Noise
Numbers of channel 2
Arbitrary waveform Exponential rise, Exponential fall, Sin(x)/x, Staircase, DC, etc. 45 built-in waveforms, User Defined
Waveform length
AFG1022 2 to 8,192
AFG1062 2 to 1M
Sampling rate
AFG1022 125 MS/s
AFG1062 300 MS/s
Resolution 14 bits
Number of non-volatile 256
waveform memories
Memory size 64 Mbyte for waveform storage
