AFG1000 Series Specifications and Performance Verification
Specifications
Table 9: Output characteristics
Characteristic Description PV ref page
Sine wave
Flatness
(at 1.0 V
p-p
amplitude, relative to 1 kHz)
AFG1022 < 10 MHz: ±0.4 dB
10 MHz ≤ frq ≤ 25 MHz: ±0.7 dB
AFG1062 < 10 MHz: ±0.5 dB
10 MHz ≤ frq ≤ 60 MHz: ±0.9 dB
Harmonic distortion (at 1.0 V
p-p
amplitude)
AFG1022 1 μHz to 25 MHz : < –50 dBc
AFG1062 Typical (0 dBm) DC to 10 MHz (included): <-60 dBc
10 MHz to 60 MHz (included): <-47 dBc
(See page 26,
AC flatness
test.)
(See page 28,
Harmonics
distortion test.)
Total harmonic
distortion (THD)
(at 1 V
p-p
amplitude)
10 Hz to 20 kHz: < 0.2%
(See page 30,
Total harmonic
distortion test.)
Phase noise, typical (at 1 V
p-p
amplitude)
1 MHz: < –110 dBc/Hz at 10 kHz offset
Spurious (nonharmonic) (at 1 V
p-p
amplitude)
Typical (0 dBm): <-45 dBc
Residual clock noise, typical –57 dBm
Square wave
Rise time/fall time
(at 1 V
p-p
amplitude), typical
AFG1022 < 12 ns
AFG1062
< 10 ns
Jitter (rms), typical
AFG1022 < 1 ns
AFG1062 < 500 ps
Overshoot < 5%
Duty Cycle 50% fixed
Pulse
Pulse width
AFG1022 40 ns to 999 ks
AFG1062
17 ns to 999 ks
Resolution 1 ns or 4 digits
Duty Cycle
AFG1022
< 1 MHz: Adjustable Duty
1 MHz ≤ frq ≤ 12.5 MHz: 50%
(limitations of pulse duty width apply)
AFG1062 < 1 MHz: Adjustable Duty
1 MHz ≤ frq ≤ 30 MHz: 50%
(limitations of pulse duty width apply)
