Tektronix AFG1062 Technical Reference

16
AFG1000 Series Specifications and Performance Verification
Performance tests
Frequency, Amplitude, DC Offset, Counter, and AC Flatness Test Record (cont.)
CH2 DC Offset Minimum Test result Maximum
+5.000 Vdc (+5.000 × CF - 0.051) Vdc (+5.000 × CF + 0.051) Vdc
+2.000 Vdc (+2.000 × CF - 0.021) Vdc (+2.000 × CF + 0.021) Vdc
+1.000 Vdc (+1.000 × CF - 0.011) Vdc (+1.000 × CF + 0.011) Vdc
0.000 Vdc -0.001 Vdc +0.001 Vdc
-1.000 Vdc (-1.000 × CF - 0.011) Vdc (-1.000 × CF + 0.011) Vdc
-2.000 Vdc (-2.000 × CF - 0.021) Vdc (-2.000 × CF + 0.021) Vdc
-5.000 Vdc (-5.000 × CF - 0.051) Vdc (-5.000 × CF + 0.051) Vdc
Counter
Frequency Minimum Test result Maximum
Sine at 1.000000 MHz 999.990 kHz 1.00009 MHz
Pulse at 1.000000 MHz 999.990 kHz 1.00009 MHz
AC Flatness (AFG1022)
CH1 AC Flatness
Minimum
Test result
Maximum
Frequency 1.00 kHz
(Ampl: 1.000 V
p-p
)
———-
dB ( = Reference)
———-
Frequency 500.00 kHz
Reference - 0.40 dB
dB
Reference + 0.40 dB
Frequency 1.00 MHz
Reference - 0.40 dB
dB
Reference + 0.40 dB
Frequency 5.00 MHz
Reference - 0.40 dB
dB
Reference + 0.40 dB
Frequency 15.00 MHz
Reference - 0.70 dB
dB
Reference + 0.70 dB
Frequency 25.00 MHz
Reference - 0.70 dB
dB
Reference + 0.70 dB
CH2 AC Flatness
Minimum
Test result
Maximum
Frequency 1.00 kHz
(Ampl: 1.000 V
p-p
)
———-
dB
( = Reference)
———-
Frequency 500.00 kHz
Reference - 0.40 dB
dB
Reference + 0.40 dB
Frequency 1.00 MHz
Reference - 0.40 dB
dB
Reference + 0.40 dB
Frequency 5.00 MHz
Reference - 0.40 dB
dB
Reference + 0.40 dB
Frequency 15.00 MHz
Reference - 0.70 dB
dB
Reference + 0.70 dB
Frequency 25.00 MHz
Reference - 0.70 dB
dB
Reference + 0.70 dB
AC Flatness (AFG1062)
CH1 AC Flatness
Minimum
Test result
Maximum
Frequency 1.00 kHz
(Ampl: 1.000 V
p-p
)
———-
dB ( = Reference)
———-
Frequency 100.00 kHz
Reference - 0.50 dB
dB
Reference + 0.50 dB
Frequency 1.00 MHz
Reference - 0.50 dB
dB
Reference + 0.50 dB
Frequency 5.00 MHz
Reference - 0.50 dB
dB
Reference + 0.50 dB
Frequency 15.00 MHz
Reference - 0.90 dB
dB
Reference + 0.90 dB
Frequency 25.00 MHz
Reference - 0.90 dB
dB
Reference + 0.90 dB
Frequency 60.00 MHz
Reference - 0.90 dB
dB
Reference + 0.90 dB
