Performance tests
AFG1000 Series Specifications and Performance Verification
29
4. Set up the spectrum analyzer according the frequency setup of the arbitrary
function generator.
5. Set the Ref Level of the spectrum analyzer to 8 dBm.
6. Read the signal level in the Fundamental frequency for each signal. Use this
level as a Reference value in step 4.
7. Verify that the differences between the reference level and the signal level in
the frequency of higher-order at each frequency are below the limit specified
in the following table.
8. Repeat steps 1 through 7 for the channel 2 output.
AFG1022 Spectrum Analyzer Measurement Limit
Frequency
Center
Frequency
Span
RBW
Fundamental
(= Reference)
2nd
3rd
4th
5th
Nth -
Reference
20.00 kHz
100 kHz
200 kHz
500 Hz
20 kHz
40 kHz
60 kHz
80 kHz
100 kHz
< -50 dBc
100.00 kHz
500 kHz
1 MHz
2 kHz
100 kHz
200 kHz
300 kHz
400 kHz
500 kHz
< -50 dBc
1.00 MHz
5.00 MHz
10 MHz
20 kHz
1 MHz
2 MHz
3 MHz
4 MHz
5 MHz
< -50 dBc
25.00 MHz 125 MHz 250 MHz 20 kHz 25 MHz 50 MHz 75 MHz 100 MHz 125 MHz < -50 dBc
AFG1062 Spectrum Analyzer Measurement Limit
Frequency
Center
Frequency
Span
RBW
Fundamental
(= Reference)
2nd
3rd
4th
5th
Nth -
Reference
20.00 kHz
100 kHz
200 kHz
500 Hz
20 kHz
40 kHz
60 kHz
80 kHz
100 kHz
< -60 dBc
100.00 kHz
500 kHz
1 MHz
2 kHz
100 kHz
200 kHz
300 kHz
400 kHz
500 kHz
< -60 dBc
1.00 MHz
5.00 MHz
10 MHz
20 kHz
1 MHz
2 MHz
3 MHz
4 MHz
5 MHz
< -60 dBc
25.00 MHz 125 MHz 250 MHz 20 kHz 25 MHz 50 MHz 75 MHz 100 MHz 125 MHz < -47 dBc
60.00 MHz
250MHz
500 MHz
20 kHz
60 MHz
120 MHz
180 MHz
240 MHz
300 MHz
< -47 dBc
