Tektronix AFG3000C Series Technical Reference

Specifications
Table 10: Output characteristics (cont.)
Characteristic Description
PV reference
page
AFG3021B / 3021C /
3022B / 3022C
≤ 14 ns
AFG3051C / 3052C
≤ 10 ns
AFG3101 / 3101C / 3102
/ 3102C
≤ 8ns
AFG3151C / 3152C
≤ 5ns
AFG3251 / 3251C / 3252
/ 3252C
≤ 3ns
Jitter (rms), typical
AFG3011 / 3011C /
3021B / 3021C / 3022B /
3022C
4ns
AFG3051C / 3052C /
3101 / 3101C / 3102 /
3102C
1nsat1GS/s
4 ns at 250 MS/s
AFG3151C / 3152C 750 ps at 1 GS/s
4 ns at 250 MS/s
AFG3251 / 3251C / 3252
/ 3252C
500 ps at 2 GS/s
4 ns at 250 MS/s
1
Exclude harmonics and channel crosstalk.
Table 11: Modulation
Characteristic Description
AM (Amplitude Modulation)
Carrier waveforms Standard waveforms (except Pulse, DC, and Noise) and Arb
Modulation source Internal or External
Internal modulating
waveforms
Sine, Square, Ramp, Noise, and Arb
1
Internal modulating frequency
2 mHz to 50.00 kHz
Depth
0.0% to 120.0%
FM (Frequency Modulation)
Carrier waveforms Standard waveforms (except Pulse, DC, and Noise) and Arb
Modulation source Internal or External
Internal modulating
waveforms
Sine, Square, Ramp, Noise, and Arb
2
Internal modulating frequency
2 mHz to 50.00 kHz
Peak deviation
AFG3011 / 3011C DC to 5 MHz
AFG3000C and AFG3000 Series Specifications and Performance Verification 15
