Performance verification
Performance t
ests
The Performance Tests include functional tests, such as the interface functional
test, in this manual.
The Functional Tests verify the functions; they verify that the AFG3000
Series Arbitrary Function Generators features operate. They do not verify
that they op
erate within limits.
The Performance Tests verify that the AFG3000 Series Arbitrary Function
Generator
s performs as warranted. The Performance Tests check all the
characteristics that are designated as checked in Specifications.
Table 18: Performance test items
Titles Test items Reference Page
Frequency/Period Test Internal clock output frequency accuracy (See page 51,
Frequen
cy/period test.)
Amplitude Test Amplitude accuracy
(See pa
ge 52, Amplitude
test.)
DC Offset Test
Ampli
tude accuracy
(See page 54, DC Offset
test.)
AC Flatness Test AC Flatness (See page 56, AC
Flat
ness test.)
Harmonic Distortion Test Harmonic Distortion
(See
page 59,
Harmonics Distortion
test.)
THD (Total Harmonic Distortion) Test
Total Harmonic Distortion
(See page 62, To ta l
Har
monic Distortion
test.)
Spurious Test Spurious (See page 64, Spurious
test.)
Rise-Fall Time Test Rise-Fall Time
(See page 67, Rise-Fall
t
ime test.)
Performance conditions
The tests in this section comprise an extensive, valid confirmation of performance
and functionality when the following requirements are met:
The cabinet covers must be on the AFG3000 Series.
The instrument must have been performed and passed the procedures under
calibration and diagnostics.
The instrument must have been calibrated/adjusted at an ambient temperature
between +20 °C and +30 °C.
A
FG3000C and AFG3000 Series Specifications and Performance Verification 27
The instrument
must be operating at an ambient temperature between +0 °C
and +50 °C.
The instrumen
t must have had a warm-up period of at least 20 minutes.
