Tektronix DMM912

1–40 DMM912/914/916
Measurement characteristics (cont.)
Characteristics Description
Diode test
3
Test current (typical) 0.5 mA
Test voltage (typical)
3 V
Capacitance
Ranges 4 nF, 40 nF, 400 nF, 4 F, 40 F,
400 F, 4 mF, 40 mF
Accuracy
3
(% + 10 counts)
4 nF to 4 F
7
±1%
40 F to 40 mF ±3%
Frequency
4
Ranges 400 Hz, 4 kHz, 40 kHz, 400 kHz,
2 MHz
Accuracy
6
(% + 1 count)
1
400 Hz to 400 kHz ±0.01%
2 MHz ±0.15%
Sensitivity 0.5 V
p-p
Duty factor
Accuracy ±(0.1% + 0.05% per kHz) for 5 V
input
Range 15 Hz to 10 kHz (10% – 90% duty
factor)
