Parallel Output: Current Offset. Use the following steps to calibrate the parallel
output offset current.
1. Press (SHIFT) OUT 2; verify that the “2” indicator lights up on the display.
2. Press (SHIFT) CURRENT
.
3. Enter the calibration password on the keypad:
PS2520 & PS2520G: enter 2520 (
)
PS2521 & PS2521G: enter 2521 (
)
4. Verify that the power supply readout displays cL00, indicating calibration
mode.
5. Configure the DMM to measure 2 amperes DC.
6. Enter 4 on the power supply keypad and press (
).Verify that the “PARA”
indicator lights up on the display and the readout displays cL40, indicating
parallel output current offset calibration.
7. Enter the DMM reading on the power supply keypad and press (
). The
power supply readout will return to normal in approximately 10 seconds.
The calibration is complete.
Parallel Output: Current Full Scale. Use the following steps to calibrate the parallel
output full-scale current.
1. Press (SHIFT) OUT 2; verify that the “2” indicator lights up on the display.
2. Press (SHIFT) CURRENT
.
3. Enter the calibration password on the keypad:
PS2520 & PS2520G: enter 2520 ( )
PS2521 & PS2521G: enter 2521 (
)
4. Verify that the power supply readout displays cL00, indicating calibration
mode.
5. Configure the DMM to measure 10 amperes DC.
6. Enter 4 on the power supply keypad.
7. Press VOLTS
to select the parallel output full-scale current calibration;
verify that the the readout displays cL41, indicating parallel output full-scale
calibration.
8. Press (
) on the power supply. Verify that the “PARA” indicator lights up
on the display.
