Installation
Signal Path Compensation
Signal Path Compensation (SPC) corre cts for DC inaccuracies caused by temperature variations and/or long-term drift. You should
run the SPC whenever the ambient temperature has changed by more than 10 °C or once a week if you use vertical settings
of 5 mV per division or less. Failure to do so may result in the oscilloscope not meeting warranted performance levels at those
volts per division settings.
To compensate the signal path:
1. Warm up the oscilloscope f or at least
20 minute s. Remove all input signals (probes
and cables) from channel inputs. In put signals
with AC components adversely affect SPC.
DPO2000 and MSO2000 Series Oscilloscopes User Man ual 29
