Acquire the Signal
Use the side-bezel buttons to define parameters
for the inputs, such as specific s ignals to an
analog or d igital c ha nnel.
Define
Inputs
If you select Parallel, push the side-bezel
button t o enable or disable Clocked Data.
Clocked
Data
Yes|
No
Push the side-beze l button to select the Clock
Edge on which to clock data: rising edge,
falling edge, or both edges.
Clock Edge
Turn multipurpose knob a to select the Number
of Data Bits in the parallel bus.
Number of
Data Bits
(a) 16
Turn multipurpose knob a to select the desired
bit to define.
Turn multipurpose kn ob b to select the desired
analog or digital channel as the source for the
bit.
Define Bits
(a) Bit 15
(b) D15
104 MSO4000 and DPO4000 Series Oscilloscopes User Manual
