Tektronix DPO5000 Series User Manual

Analyzing wavef
orms
3. Build your advanced math waveform
expression using sources, operators,
constants, me
asurements, variables,
and functions.
4. When you have defined the expression
to your satisfaction, click Apply.
5. To add your
own filter, click the Filter
tab. Click Load.
6. Double c lick the folder for the filters y ou
want to use. Double click the filter you
want to use.
MSO/DPO70000DX, MSO/DPO70000C, DP O7000C, and MS O/DPO5000 Series U ser M anual 127
