DC gain accuracy (averaged), ≥4 GHz, ≤20 GHz models
Instrument performance test Minimum Incoming Outgoing Maximum
Ch3 200 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +1.25 V offset
+5 Div position setting, -1.25 V offset
+ 1.49 V
+ 1.49 V
+ 1.49 V
__________
__________
__________
__________
__________
__________
+ 1.55 V
+ 1.55 V
+ 1.55 V
Ch3 500 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, 0 V offset
+5 Div position setting, 0 V offset
+ 3.724 V
+ 3.724 V
+ 3.724 V
__________
__________
__________
__________
__________
__________
+ 3.876 V
+ 3.876 V
+ 3.876 V
Ch4 10 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.45 V offset
+5 Div position setting, -0.45 V offset
+ 74.48 mV
+ 74.48 mV
+ 74.48 mV
__________
__________
__________
__________
__________
__________
+ 77.52 mV
+ 77.52 mV
+ 77.52 mV
Ch4 20 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.4 V offset
+5 Div position setting, -0.4 V offset
+ 148.96 mV
+ 148.96 mV
+ 148.96 mV
__________
__________
__________
__________
__________
__________
+ 155.04 mV
+ 155.04 mV
+ 155.04 mV
Ch4 50 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.25 V offset
+5 Div position setting, -0.25 V offset
+ 372.40 mV
+ 372.40 mV
+ 372.40 mV
__________
__________
__________
__________
__________
__________
+ 387.60 mV
+ 387.60 mV
+ 387.60 mV
Ch4 100 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +2.0 V offset
+5 Div position setting, -2.0 V offset
+ 744.80 mV
+ 744.80 mV
+ 744.80 mV
__________
__________
__________
__________
__________
__________
+ 775.20 mV
+ 775.20 mV
+ 775.20 mV
Ch4 200 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +1.25 V offset
+5 Div position setting, -1.25 V offset
+ 1.49 V
+ 1.49 V
+ 1.49 V
__________
__________
__________
__________
__________
__________
+ 1.55 V
+ 1.55 V
+ 1.55 V
Ch4 500 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, 0 V offset
+5 Div position setting, 0 V offset
+ 3.724 V
+ 3.724 V
+ 3.724 V
__________
__________
__________
__________
__________
__________
+ 3.876 V
+ 3.876 V
+ 3.876 V
Offset accuracy, >20 GHz models
Instrument performance test Minimum Incoming Outgoing Maximum
Ch1 6.25 mV Vert scale, 0 Div position setting,
0 V offset, 0 V termination
+3.4 V offset, +3.5 V termination
-3.4 V offset, -3.5 V termination
–3.13 mV
+3.3831 V
–3.4169 V
__________
__________
__________
__________
__________
__________
+3.125 mV
+3.4169 V
–3.3831 V
Ch1 10 mV Vert scale, 0 Div position setting,
0 V offset, 0 V termination
+3.4 V offset, +3.5 V termination
-3.4 V offset, -3.5 V termination
–3.5 mV
+3.3827 V
–3.4173 V
__________
__________
__________
__________
__________
__________
+3.5 mV
+3.4173 V
–3.3827 V
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
