Male-to-male connectors Tektronix part number 012-0057-01
9. Optical Mouse
USB, PS2 Tektronix part number 119-7054-00; standard
accessory for MSO5000/B Series and
DPO5000/B Series oscilloscopes.
You might need additional cables and adapters, depending on the actual test
equipment you use.
These procedures cover all MSO5000/B series and DPO5000/B series models.
Disregard checks that do not apply to the specific model you are testing.
Print the test record on the following pages and use it to record the performance
test results for your oscilloscope.
NOTE. Completion of the performance verification procedure does not update the
stored time and date of the latest successful adjustment. The date and time are
updated only when the adjustment procedures in the service manual are
successfully completed.
The performance verification procedures verify the performance of your
instrument. They do not adjust your instrument. If your instrument fails any of
the performance verification tests, you should return the instrument to Tektronix
for adjustment or repair.
Test record
Model Serial Procedure performed by Date
Test Passed Failed
Self Test
Input Impedance
Performance checks Vertical scale Low limit Test result High limit
Channel 1 Input
Impedance, 1 MΩ
10 mV/div 990 kΩ 1.01 MΩ
100 mV/div 990 kΩ 1.01 MΩ
1 V/div 990 kΩ 1.01 MΩ
Channel 1 Input
Impedance, 250 kΩ
100 mV/div 246 kΩ 254 kΩ
Channel 1 Input
Impedance, 50 Ω
10 mV/div 49.5 Ω 50.5 Ω
100 mV/div 49.5 Ω 50.5 Ω
Performance verification (MSO/DPO5000/B series)
286 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
