Tektronix DPO70000C/DX Series Technical Reference

Input Impedance
Performance checks Vertical scale Low limit Test result High limit
Channel 2 Input
Impedance, 1 MΩ
10 mV/div 990 kΩ 1.01 MΩ
100 mV/div 990 kΩ 1.01 MΩ
1 V/div 990 kΩ 1.01 MΩ
Channel 2 Input
Impedance, 250 kΩ
100 mV/div 246 kΩ 254 kΩ
Channel 2 Input
Impedance, 50 Ω
10 mV/div 49.5 Ω 50.5 Ω
100 mV/div 49.5 Ω 50.5 Ω
Channel 3 Input
Impedance, 1 MΩ
10 mV/div 990 kΩ 1.01 MΩ
100 mV/div 990 kΩ 1.01 MΩ
1 V/div 990 kΩ 1.01 MΩ
Channel 3 Input
Impedance, 250 kΩ
100 mV/div 246 kΩ 254 kΩ
Channel 3 Input
Impedance, 50 Ω
10 mV/div 49.5 Ω 50.5 Ω
100 mV/div 49.5 Ω 50.5 Ω
Channel 4 Input
Impedance, 1 MΩ
10 mV/div 990 kΩ 1.01 MΩ
100 mV/div 990 kΩ 1.01 MΩ
1 V/div 990 kΩ 1.01 MΩ
Channel 4 Input
Impedance, 250 kΩ
100 mV/div 246 kΩ 254 kΩ
Channel 4, Input
Impedance, 50 Ω
10 mV/div 49.5 Ω 50.5 Ω
100 mV/div 49.5 Ω 50.5 Ω
DC Balance
Performance checks Vertical scale Low limit Test result High limit
Channel 1 DC Balance,
50 Ω, 20 MHz BW
1 mV/div -0.2 mV 0.2 mV
2 mV/div -0.2 mV 0.2 mV
5 mV/div -0.5 mV 0.5 mV
10 mV/div -1 mV 1 mV
20 mV/div -2 mV 2 mV
50 mV/div -5 mV/div 5 mV/div
100 mV/div -10 mV 10 mV
200 mV/div -20 mV/div 20 mV/div
500 mV/div -50 mV/div 50 mV/div
1 V/div -100 mV 100 mV
Performance verification (MSO/DPO5000/B series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 287
