Random Noise, Sample Acquisition Mode
Performance checks Vertical sensitivity = 100 mV/div
1 MΩ 50 Ω
Bandwidth Test result (mV) High limit (mV) Test result (mV) High limit (mV)
MSO5204, DPO5204
Channel 1 Full 8.18 6.15
250 MHz limit 5.12 4.08
20 MHz limit 5.12 4.08
Channel 2 Full 8.18 6.15
250 MHz limit 5.12 4.08
20 MHz limit 5.12 4.08
Channel 3 Full 8.18 6.15
250 MHz limit 5.12 4.08
20 MHz limit 5.12 4.08
Channel 4 Full 8.18 6.15
250 MHz limit 5.12 4.08
20 MHz limit 5.12 4.08
MSO5104, DPO5104
Channel 1 Full 8.15 6.08
250 MHz limit 5.10 4.05
20 MHz limit 5.10 4.05
Channel 2 Full 8.15 6.08
250 MHz limit 5.10 4.05
20 MHz limit 5.10 4.05
Channel 3 Full 8.15 6.08
250 MHz limit 5.10 4.05
20 MHz limit 5.10 4.05
Channel 4 Full 8.15 6.08
250 MHz limit 5.10 4.05
20 MHz limit 5.10 4.05
MSO5034, DPO5034, MSO5054, DPO5054
Channel 1 Full 8.13 8.13
250 MHz limit 6.10 6.10
20 MHz limit 4.10 4.10
Channel 2 Full 8.13 8.13
250 MHz limit 6.10 6.10
20 MHz limit 4.10 4.10
Performance verification (MSO/DPO5000/B series)
300 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
