Tektronix DPO70000C/DX Series Technical Reference

10 GS/s
Step gain 0.5 GHz 0.025 GHz 0.02 GHz
50 mV/div 1.6 mV 1.45 mV 1.38 mV
20 mV/div 0.645 mV 0.58 mV 0.55 mV
10 mV/div 0.34 mV 0.3 mV 0.277 mV
5 mV/div 0.21 mV 0.165 mV 0.141 mV
2 mV/div 0.13 mV 0.1 mV 0.062 mV
1 mV/div 0.096 mV 0.097 mV 0.04 mV
5 GS/s
Step gain 0.5 GHz 0.025GHz 0.02 GHz
500 mV/div 15.1 mV 14.0 mV 13.2 mV
200 mV/div 6.35 mV 5.7 mV 5.4 mV
100 mV/div 3.4 mV 2.95 mV 2.75 mV
50 mV/div 1.6 mV 1.45 mV 1.38 mV
20 mV/div 0.645 mV 0.58 mV 0.55 mV
10 mV/div 0.34 mV 0.3 mV 0.277 mV
5 mV/div 0.21 mV 0.165 mV 0.141 mV
2 mV/div 0.13 mV 0.1 mV 0.062 mV
1 mV/div 0.096 mV 0.097 mV 0.04 mV
2.5 GS/s
Step gain 0.5 GHz 0.025GHz 0.02 GHz
500 mV/div 15.1 mV 14.0 mV 13.2 mV
200 mV/div 6.35 mV 5.7 mV 5.4 mV
100 mV/div 3.4 mV 2.95 mV 2.75 mV
50 mV/div 1.6 mV 1.45 mV 1.38 mV
20 mV/div 0.645 mV 0.58 mV 0.55 mV
10 mV/div 0.34 mV 0.3 mV 0.277 mV
5 mV/div 0.21 mV 0.165 mV 0.141 mV
2 mV/div 0.13 mV 0.1 mV 0.062 mV
1 mV/div 0.096 mV 0.097 mV 0.04 mV
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Vertical system analog channels
(cont.)
46 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
