Maximum record length, sample
mode <4 GHz models
The maximum record length depends on the number of active channels and the record length
options installed. Maximum record length is less in serial trigger mode, hi-res mode or when using
the FIR filter.
Standard, DPO7354C and
DPO7254C
10 GS/s
20 GS/s or less
40 GS/s or less
12,500,000 points (3 or 4 channels)
25,000,000 points (2 channels)
50,000,000 points (1 channel)
DPO7104C
5 GS/s
10 GS/s or less
20 GS/s or less
12,500,000 points (3 or 4 channels)
25,000,000 points (2 channels)
50,000,000 points (1 channel)
DPO7054C
2.5 GS/s
5 GS/s or less
10 GS/s or less
12,500,000 points (3 or 4 channels)
25,000,000 points (2 channels)
50,000,000 points (1 channel)
Option 2RL installed,
DPO7354C and DPO7254C
10 GS/s
20 GS/s or less
40 GS/s or less
25,000,000 points (3 or 4 channels)
50,000,000 points (2 channels only)
125,000,000 points (1 channel only)
DPO7104C
5 GS/s
10 GS/s or less
20 GS/s or less
25,000,000 points (3 or 4 channels)
50,000,000 points (2 channels only)
125,000,000 points (1 channel only)
DPO7054C
2.5 GS/s
5 GS/s or less
10 GS/s or less
25,000,000 points (3 or 4 channels)
50,000,000 points (2 channels only)
125,000,000 points (1 channel only)
Option 5RL installed,
DPO7354C and DPO7254C
10 GS/s
20 GS/s or less
40 GS/s or less
50,000,000 points (3 or 4 channels)
125,000,000 points (2 channels only)
250,000,000 points (1 channel only)
DPO7104C
5 GS/s
10 GS/s or less
20 GS/s or less
50,000,000 points (3 or 4 channels)
125,000,000 points (2 channels only)
250,000,000 points (1 channel only)
DPO7054C
2.5 GS/s
5 GS/s or less
10 GS/s or less
50,000,000 points (3 or 4 channels)
125,000,000 points (2 channels only)
250,000,000 points (1 channel only)
Option 10RL installed,
DPO7354C and DPO7254C
10 GS/s
20 GS/s or less
40 GS/s or less
125,000,000 points (3 or 4 channels)
250,000,000 points (2 channels only)
500,000,000 points (1 channel only)
Maximum record length, HiRes
mode
Half the record length of sample mode
Horizontal and acquisition system (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 49
