MSO/DPO70804C, MSO/
DPO70604C at 500 GS/s (IT
mode), 6 GHz, BWE on
10 mV/div, <10 ns measurement interval, 3.73 GHz, amplitude = 80% FS, 1.445 ps rms,
14.45 ps
pk-pk
50 mV/div, <10 ns measurement interval, 3.73 GHz, amplitude = 80% FS, 1.295 ps rms,
12.95 ps
pk-pk
100 mV/div, <10 ns measurement interval, 3.73 GHz, amplitude = 80% FS, 1.329 ps rms,
13.29 ps
pk-pk
MSO/DPO70804C, MSO/
DPO70604C, MSO/DPO70404C
at 500 GS/s (IT mode), 4 GHz,
BWE on
10 mV/div, <10 ns measurement interval, 2.48 GHz, amplitude = 80% FS, 1.674 ps rms,
16.74 ps
pk-pk
50 mV/div, <10 ns measurement interval, 2.48 GHz, amplitude = 80% FS, 1.437 ps rms,
14.37 ps
pk-pk
100 mV/div, <10 ns measurement interval, 2.48 GHz, amplitude = 80% FS, 1.478 ps rms,
14.78 ps
pk-pk
Delta time measurement
accuracy <4 GHz models
For signals having amplitude greater than 5 divisions, reference level = 50%, filter set to sin(x)/x,
acquired at 10 mV/div or greater. The displayed risetime/sample interval must be greater than
1.4 but less than 4. Extra error will occur for two channel measurements due to channel to channel
skew. Peak specification is based on statistical accumulation of 1000 waveforms.
Single shot, sample or HiRes, full bandwidth (0.06/sample rate + 2.5 ppm x | reading |)RMS
± (0.30/(sample rate) + (2.5 ppm x | reading |))
peak
Average Mode, ≥100 averages, full bandwidth
selected.
± (2.5 ppm x | reading | + 4 ps)
Horizontal and acquisition system (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 57
