Tektronix DPO70000C/DX Series Technical Reference

Trigger level or threshold
accuracy, typical
Edge trigger, DC coupled
≥4 GHz models
Trigger Source Accuracy
Channel 1, 2, 3, or 4 ± [(2% | trigger level - net offset | ) + (3.5% FS)
+ offset accuracy]
Auxiliary Not specified
<4 GHz models
Trigger Source Accuracy
Channel 1, 2, 3, or 4 ± [(2% | deflection | ) + (0.7 divisions ×
Auxiliary Not specified
Trigger position error, typical Edge trigger, DC coupling, for signals having a slew rate at the trigger point of ≥ 0.5 divisions/ns
≥4 GHz models
Acquisition mode Trigger Position Error
Sample, Average ± (1 waveform interval + 50 ps)
Peak Detect, Envelope ± (2 waveform intervals + 50 ps)
<4 GHz models
Acquisition mode Trigger Position Error
Sample, Average ± (1 waveform interval + 200 ps)
Peak Detect, Envelope ± (2 waveform intervals + 200 ps)
Time range for time-qualified
triggers
≥4 GHz models
Setup/Hold Violation
Setup time
Hold time
Setup + hold time
-100 ns to +100 ns
-1 ns to +100 ns
500 ps minimum
Timeout 400 ps to 1 s
Time qualified window, outside >t 600 ps to 1 s
All other types 300 ps to 1 s
<4 GHz models 300 ps to 1 s
Time-qualified trigger timer
accuracy
For Glitch, Width, Time qualified runt, Transition, or Setup/hold violation types
≥4 GHz models
Time range Accuracy
Glitch and width triggering (300 ps to 1.0 ns typical)
<300 ns to 1.01 μs ±(3% of setting + 80 ps)
1.02 μs to 1 s ±(TB accuracy + 100 ns)
Other time-qualified types (300 ps to 1.0 ns typical)
<300 ps to 1.01 μs ±(5% of setting + 200 ps)
1.02 μs to 1 s ±(TB accuracy + 20 ns)
<4 GHz models
Time range Accuracy
<1 μs (<2 ns typical) ±(20% of setting + 0.5 ns)
1 μs to 1 s ±(0.01% of setting + 100 ns)
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Trigger specifications (cont.)
60 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series

Tektronix DPO70000C/DX Series Specifications
