Tektronix DPO70000C/DX Series Technical Reference

Instrument TPP1000 probe
50 mV/div to
100 mV/div
TP1000 probe
20 mV/div to
49.8 mV/div
TPP1000 probe
10 mV/div to
19.9 mV/div
MSO5204/B, DPO5204/B 350 ps I ns 2 ns
MSO5104/B, DPO5104/B 350 ps I ns 2 ns
MSO5054/B, DPO5054/B 700 ps I ns 2 ns
MSO5034/B, DPO5034/B I ns I ns 2 ns
Instrument TPP0500 probe
50 mV/div to
10 V/div
TPP0500 probe
20 mV/div to
49.8 mV/div
TPP0500 probe
10 mV/div to
19.9 mV/div
MSO5204/B, DPO5204/B 700 ps I ns 2 ns
MSO5104/B, DPO5104/B 700 ps I ns 2 ns
MSO5054/B, DPO5054/B 700 ps I ns 2 ns
MSO5034/B, DPO5034/B I ns I ns 2 ns
Peak detect or envelope mode
pulse response, typical
Instrument
(Sample Rate Maximum)
Minimum pulse width
MSO5204/B, DPO5204/B,
MSO5104/B, DPO5104/B
>100 ps
MSO5054/B, DPO5054/B,
MSO5034/B, DPO5034/B
>200 ps
Effective bits, typical Specifications are valid at maximum per channel sample rate and at 1k record length.
Model Input frequency Effective bits
MSO5204/B,
DPO5204/B
4.9 MHz 6.0 bits
2 GHz 6.0 bits
MSO5104/B,
DPO5104/B
4.9 MHz 6.0 bits
1 GHz 6.0 bits
MSO5054/B,
DPO5054/B
4.9 MHz 6.0 bits
500 MHz 6.0 bits
MSO5034/B,
DPO5034/B
4.9 MHz 6.0 bits
350 MHz 6.0 bits
Specifications (MSO/DPO5000/B Series) Analog channel input and vertical specification (cont.)
