Tektronix DPO70000C/DX Series Technical Reference

MSO/DPO5204B 50 Ω termination 1 MΩ termination
Vertical Setting Full BW 250 MHz
BW
20 MHz
BW
Full BW 250 MHz
BW
20 MHz
BW
10 mV/div 0.65 0.37 0.33 0.85 0.45 0.45
20 mV/div 1.10 0.75 0.60 1.10 0.80 0.80
50 mV/div 2.50 1.90 1.50 2.30 2.00 1.90
100 mV/div 6.1 3.7 3.1 5.0 3.8 4.0
1 V/div 43.0 38.0 30.5 50.0 37.5 35.0
MSO/DPO5104B 50 Ω termination 1 MΩ termination
Vertical Setting Full BW 250 MHz
BW
20 MHz
BW
Full BW 250 MHz
BW
20 MHz
BW
1 mV/div 0.09 0.07 0.21 0.11
2 mV/div 0.17 0.12 0.10 0.38 0.20 0.13
5 mV/div 0.28 0.20 0.18 0.55 0.28 0.23
10 mV/div 0.45 0.37 0.33 0.65 0.45 0.40
20 mV/div 0.80 0.75 0.60 1.00 0.80 0.80
50 mV/div 2.00 1.90 1.50 2.30 2.00 1.90
100 mV/div 4.5 3.7 3.0 4.5 3.8 4.0
1 V/div 40.0 38.0 30.0 45.0 37.5 35.0
MSO/DPO5054B 50 Ω termination
Vertical Setting Full BW 250 MHz BW 20 MHz BW
1 mV/div 0.20 0.11
2 mV/div 0.27 0.21 0.13
5 mV/div 0.38 0.30 0.22
10 mV/div 0.55 0.55 0.45
20 mV/div 1.10 1.00 0.80
50 mV/div 2.50 2.50 1.90
100 mV/div 5.0 4.75 4.0
1 V/div 50.0 50.0 40.0
MSO/DPO5054B 50 Ω termination
Vertical Setting Full BW 250 MHz BW 20 MHz BW
1 mV/div 0.20 0.11
2 mV/div 0.27 0.21 0.13
5 mV/div 0.38 0.30 0.22
10 mV/div 0.55 0.55 0.45
20 mV/div 1.10 1.00 0.80
50 mV/div 2.50 2.50 1.90
100 mV/div 5.0 4.75 4.0
Specifications (MSO/DPO5000/B Series) Analog channel input and vertical specification (cont.)
84 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
