Replaceable Parts (DPO7000 Series)
Replaceable P
arts (DPO7000 Series)
Table 5-1: Re
placeable parts – External (DPO7000 Series)
Fig. &
index
number
Tektronix
part
number
Serial no.
effective
Serial no.
discont’d Qty Name & description
5-1
EXTERNAL PART S
-1 016-1966-00 1
POUCH; ACCESSORIES, BLACK, SNAP-ON
-2 200-4956-00 1
COVER,TOP;COSMETIC
-3 211-1224-00 8
SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
-4 200-4954-00 1
COVER; EMI TOP, SAFETY CONTROLLED
-5
348-1861-00 4
FOOT; REAR, ASSY. W/ CORD WRAP, THERMOPLASTIC, SRY
-6 174-5227-00 1
CABLE ASSY; LINE FILTER; SAFETY CONTROLLED
-7
200-4958-00 1
COVER, LEFT; COSMETIC STINGRAY
-8 212-0232-00
SCREW, MACHINE: 8-32 X 1.125L, PNH, STL, BLACK OXIDE, T-20
367-0528-00 1
HANDLE, CARRYING; DUAL DUROMETER MOLDED,
POLYPROPYLENE, VINYL GRIP SECTION, SAFETY CONTROLLED
-9
407-4887-00 1
BRACKET: HANDLE BASE, PC/ABS ALLOY, BAYER BAYBLEND
FR-110,TEK BLUE
-10 200-4955-00 1
COVER; EMI BOTTOM, SAFETY CONTROLLED
101-0172-00 1
TRIM, ACQUISITION INSERT (VPI ONLY)
-11
101-0173-00 1
TRIM, ACQUISITION INSERT (HPI ONLY)
-12 200-4963-00 1
COVER, F RONT; PC/ABS ALLOY BAYBLEND
335-1757-00 1
MARKER, IDENT; LABEL, IDENTIFICATION; (7354 ONLY)
335-1520-00 1
MARKER,IDENT; LABEL,IDENTIFICATION; (7254 ONLY)
335-1551-00 1
MARKER, IDENT; LABEL, IDENTIFICATION; (7104 ONLY)
-13
335-1552-00 1
MARKER, IDENT; LABEL, IDENTIFICATION; (7054 ONLY)
-14 101-0174-00 1 TRIM, DVD
-15 101-0171-00 1
TRIM RING; FR110, PC/ABS
-16 200-4957-00 1
COVER, RIGHT; COSMETIC STINGRAY
-17 355-0303-00 4
STUD.SNAP: 0.570 DIA, 0.165 THK, STAINLESS STEEL
-18 211-0721-00 4
SCREW,MACHINE; 6-32 X 0.375,PNH,STL,CDPL,T-15 TORX DR
335-1517-00 1
LABEL, REAR, LEXAN, MOTHERBOARD TAPPEN, SAFETY
CONTROLLED, 039-0173-xx
-19
335-2011-00
LABEL, REAR, LEXAN, MOTHERBOARD ADVANTECH AIMB-562,
SAFETY CONTROLLED, 039-0185-xx
MSO70000/C, DSA70000B/C, DPO70000B/C, D PO7000, MSO5000, DPO5000 Series 5–3
