Tektronix MSO2000 series Instruction Manual

Giving Demos of MSO Features
Demo XXI: Triggering on Parallel Bus Data Values (MSO2000, MSO3000, and MSO4000 Models)
The MSO4000, MSO3000, and MSO2000 can trigger on specific parallel bus data values.
1. Push the front-panel Trigger Menu button.
2. Push t he lower-bezel Type button.
Type
Bus
Source Bus
B1 Parallel
Data
XX
Mode
Auto
& Holdoff
3. Turn multipurpose knob a to select Bus.
Demo 2 Board Instruction Manua l 99
