Tektronix MSO2000 series Technical Reference

Performance Verification
DC Offset Accuracy
Performance
checks Vertical scal
e
Vertical offs
et
1
Low limit Test result
High limit
All models:
1mV/div
900 mV 895.0 mV 905.0 mV
1mV/div
-900 mV -905.0 m V -895.0 m V
2mV/div
500 mV 497.0 mV 503.0 mV
2mV/div
-500 mV -503.0 m V -497.0 m V
10 mV/div
500 mV 495.5 mV 504.5 mV
10 mV/div
-500 mV -504.5 m V -495 mV
100 mV/div
5.0 V 4.955 V 5.045 V
Channel 1 DC Offset
Accuracy,
20 MHz BW, 50 Ω
100 mV/div
-5.0 V -5.045 V -4.955 V
1mV/div
900 mV 895.2 mV 904.8 mV
1mV/div
-900 mV -904.8 m V -895.2 m V
2mV/div
500 mV 497.1 mV 502.9 mV
2mV/div
-500 mV -502.9 m V -497.1 m V
10 mV/div
500 mV 495.5 mV 504.5 mV
10 mV/div
-500 mV -504.5 m V -495.5 m V
100 mV/div
5.0 V 4.955 V 5.045 V
100 mV/div
-5.0 V -5.045 V -4.955 V
1.01 V/div
99.5 V 98.80 V 100.2 V
Channel 1 DC Offset
Accuracy,
20 MHz BW, 1 MΩ
1.01 V/div
-99.5 V -100.2 V -98.80 V
1mV/div
900 mV 895.0 mV 905.0 mV
1mV/div
-900 mV -905.0 m V -895.0 m V
2mV/div
500 mV 497.0 mV 503.0 mV
2mV/div
-500 mV -503.0 m V -497.0 m V
10 mV/div
500 mV 495.5 mV 504.5 mV
10 mV/div
-500 mV -504.5 m V -495.5 m V
100 mV/div
5.0 V 4.955 V 5.045 V
Channel 2 DC Offset
Accurac
y,
20 MHz BW, 50 Ω
100 mV/div
-5.0 V -5.045 V -4.955 V
1mV/div
900 mV 895.2 mV 904.8 mV
1mV/div
-900 mV -904.8 m V -895.2 m V
2mV/div
500 mV 497.1 mV 502.9 mV
2mV/div
-500 mV -502.9 m V -497.1 m V
10 mV/div
500 mV 495.5 mV 504.5 mV
10 mV/div
-500 mV -504.5 m V -495.5 m V
100 mV/div
5.0 V 4.955 V 5.045 V
100 mV/div
-5.0 V -5.045 V -4.955 V
1.01 V/div
99.5 V 98.80 V 100.2 V
Channel 2 DC Offset
Accur
acy,
20 MHz BW, 1 MΩ
1.01 V/div
-99.5 V -100.2 V -98.80 V
26 MSO4000 and DPO4000 Series Specifications and Performance Verification
