Tektronix MSO2000 series Demo Instruction Manual

Giving Demos of Advanced Tektronix 40 00 Features
2. Push the lower-bezel Type button and select
Bus with multipurpose knob a.
Type
Bus
Source Bus
B1 RS-232
Trigger On
Tx Data
Data
51
Mode
Normal
& Holdoff
3. Push the lower-bezel Trigger On button and
use multipurpose knob a to select Tx Data.
4. Push the lower-bezel Data b utton. Enter
theHexvalue51(ASCIIcharacterQ)with
multipurpose knobs a and b.
Notice that the side-bezel menu displays the
character Q for you.
5. Push Menu Off.
6. Push Single.
64 Tektronix 4000 Oscilloscope Demo Instruction Manual
