Tektronix MSO2000 series Demo Instruction Manual

Giving Demos of MSO4000 Features
Demo XVIII: Labeling Channels
You can add custom labels to each digital waveform. As the numbe r of signals on the oscilloscope display increases, it becomes
more and more helpful to attach labels to each signa l.
NOTE. Start from where you finished the last demo. In other words, you should have pushed the front-panel D15–D0 button to
bring up the D15–D0 lower-bezel menu.
1. Connect a USB keyboard to one of the
MSO4000’s USB ports. Use either the
front-panel or a rear-pan el USB port.
Tektronix 4000 Oscilloscope Demo In struction Manual 77
