Acquire the Signal
3. Push Gl itch Capture Backg rou nd to turn off
the background waveform that contains the
higher fre quency components of the signal.
With Glitch Capture set to Off, the oscilloscope
displays only the noise filter (foreground)
waveform.
Glitch Cap-
ture Back-
ground
On |Off
4. With Glitch Capture set to On, turn
multipurpose knob b to adjust the inten s ity of
the Glitch Capture (background) waveform.
You can only adjust the intensity when filtering.
Back-
ground
Intensity
Auto
122 DPO2000 and MSO2000 S eries Oscilloscopes User Manual
