Save and Recall Information
Save
Screen
3. From the side-bezel menu, push File Format
repeatedly to select .tif, .bmp, and .png
formats.
File Format
.png
4. Push Ink Saver to turn the Ink Saver mode on
or off. When on, this mod e provides a white
background.
Ink Saver
On |
Off
5. Push Edit File Name to create a custom name
for the screen image file.Skipthissteptouse
a default name.
Edit File
Name
6. Push OK Save Screen Im age to write th e
image to the selected media.
OK Save
Screen
For information on printing screen images of waveforms, go to PrintingaHardCopy. (See page 227, Printing a Hard Copy.)
Saving and Recalling Waveform Data
Waveform d ata consists of the numeric values for each point in t he waveform. It copies the data, as opposed to a graphical image
of th e scree n. To save the current waveform data or to recall previously stored wav eform data:
216 DPO2000 and MSO2000 S eries Oscilloscopes User Manual
