Display Waveform Data
3. Push Bandwidth, and select the desired
bandwidth from the resulting side-bezel m enu.
The default choices are Full and 20 MHz.
Additional choices may appear, depending on
the probe that you use.
Select Full to set the bandwidth to the full
oscilloscope bandwidth.
Select 20 MHz to set the bandwidth to 20 MHz.
4. Push Lab el to create a label for the channel.
(See page 77, Labeling Channels and Buses.)
5. Push Probe Setup to define probe parameters.
On the resulting side-bezel menu:
Select Voltage or Current to set the
probe type for probes that do not have the
TekProbe II or TekVPI interface.
Use multipurpose knob a to set the
attenuation to match the probe.
6. Push More t o access additiona l side-bezel
menus.
DPO2000 and MSO2000 Series Oscilloscopes User Man ual 159
