Acquire the Signal
2. Push a lower-be zel button to create a label,
such as for channel 1 or B 1.
Label
3. Turn multipurpo se knob b to scroll through the
list to nd a suitable label. You can edit the
label after you insert it if necessary.
4. Push Insert Preset Label to add the label.
Insert
Preset
Label
78 DPO2000 and MSO2000 Series Oscilloscopes User Manual
