Tektronix MSO4000 Series Technical Reference

Performance Verification
Delta Time Meas
urement Accuracy
Channel 1–2 (MS
O/DPO4032)
MSO/DPO = 4 ns/Div, Source freq = 240 MHz
MSO/DPO V /D iv Source V
pp
Test result High limit
5 mV 40 mV 232 ps
100 mV 800 mV 231 ps
500 mV 4 V 231 ps
1 V 4 V 232 ps
MSO/DPO = 40 ns/Div, Source freq = 24 MHz
1 mV 8 mV 441 ps
5 mV 40 mV 281 ps
100 mV 800 mV 256 ps
500 mV 4 V 255 ps
1 V 4 V 312 ps
MSO/DPO = 400 ns/Div, Source freq = 2.4 MHz
1 mV 8 mV 3.78 ns
5mV 40mV 1.66ns
100 mV 800 mV 1.17 ns
500 mV 4 V 1.15 ns
1V 4V 2.13ns
MSO/DPO = 4 μs/Div, Source freq = 240 kHz
1mV 8mV 37.6ns
5mV 40mV 16.1ns
100 mV 800 mV 11.0 ns
500 mV 4 V 10.8 ns
1V 4V 21.0ns
MSO/DPO = 40 μs/Div, Source freq = 24 kHz
1 mV 8 mV 376 ns
5 mV 40 mV 161 ns
100 mV 800 mV 110 ns
500 mV 4 V 108 ns
1V 4V 210ns
MSO/DPO = 400 μs/Div, Source freq = 2.4 kHz
1mV 8mV 3.76μs
5mV 40mV 1.61 μs
100 mV 800 mV 1.10 μs
500 mV 4 V 1.08 μs
1V 4V 2.10 μs
MSO4000 and DPO4000 Series Specifications and Performance Verification 33
