Tektronix MSO4000 Series User Manual

Acquire the Signal
7. Push Event Table and select On to display a
list of bus packets with tim estamps.
Event
Table
On |O ff
Save Event
Table
For a clocked parallel bus, the table lists the
value of the bus at each clock edge. For an
unclocked parallel bus, the table lists the value
of the bus whenever any on e of its bits changes.
For an RS-232 bus, th e table lists decoded
bytes or packets.
8. Push Save Eve nt Table to save the event
table data in a .csv (spreadsheet) format on the
currently selected storage device.
108 MSO4000 and DPO4000 Series Oscilloscopes User Manual
