Tektronix MSO4000 Series User Manual

Save and Recall Information
5. Push To File to save to a C ompactFlash card
or USB flash drive.
To File
This brings up the file manager scre en. Use it
to define a custom file name. Skip this step to
use the default name and location.
Saving a waveform to file. When you push the To File side-bezel me nu button, the oscilloscope changes the side-bezel menu
contents. The following table describes th ese side-bezel menu items for saving data to a mass storage file.
Side-bezel menu button
Description
Internal File Format (.ISF) Sets the oscilloscope to save waveform data from analog channels (and math and re ference
waveforms derived from analog channels), in internal waveform save file (.isf) format. This format
is the fastest to write and creates the smallest-sized file. Use this format if you intend to recall a
waveform to reference memory for viewing or measuring.
The oscilloscope cannot save digital waveforms in an .isf file format.
244 MSO4000 and DPO4000 Series Oscilloscopes User Manual
