Adjustment Procedure
3. Verify that th
e calibrator is in direct mode by pushing the
lower-bezel
button until 1.0 is selected.
4. Set the calib
rator amplitude as follows:
a. Select the Amplitude field using the front-panel tab key
.
b. Set the voltage specified by the oscilloscope prompt.
5. Push the ON button and verify that the red light turns on to indicate that
the calibrator output is on.
6. On the oscilloscope, push the OK Do Next Step right-bezel button.
Sine Signal
Complete these s teps to set the calibrator output for a sine wave signal.
1. Push the Sine
front-panel button.
2. Verify t
hat the calibrator is in direct mode by pushing the
lower-bezel
button until 1.0 is selected.
3. Set the
calibrator amplitude as follows:
a. Select the Amplitude field using the front-panel tab key
.
b. Set the voltage specified by the oscilloscope prompt.
4. Set the calibrator frequency as follows:
a. Select the Frequency field using the front-panel tab key
.
b. Set the frequency specified by the oscilloscope p rompt.
5. Set
the calibrator output channels and impedance as follows:
a. Push the CHANNEL SELECT lower-bezel button.
b. Select the c hannel(s) specified by the oscilloscope prompt.
c. Push the LOAD lower-bezel button to highlight either 1MΩ or 50 Ω,as
specified by the oscilloscope prompt.
d. Push the EXIT lower bezel button.
6. Push the ON button and verify that the red light turns on to indicate that
the calibrator output is on.
7. On the oscilloscope, push the OK Do Next Step right-bezel button.
MSO4000B and DPO4000B Series Digital Phosphor Oscilloscopes Service Manual 15
