Tektronix MSO4000B Series Service Manual

General Safety Summary
TermsinThisManual
These terms may
appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
Symbols and Terms on the
Product
These terms may appear on the product:
DANGER in
dicates an injury hazard immediately accessible as you read
the m arking.
WARN IN G
indicates an injury hazard not immediately a ccessible as you
read the marking.
CAUTIO
N indicates a hazard to property including the product.
The following symbol(s) may appear on the product:
MSO4000B and DPO4000B Series Digital Phosphor Oscilloscopes Service Manual v

Tektronix MSO4000B Series Specifications

General

Analog Channels	2 or 4
Vertical Resolution	8 bits
Operating Temperature	0 °C to +50 °C
Digital Channels	16
Memory Depth/Record Length	20M standard on all channels
Display	10.4-inch (264 mm) LCD color display
Connectivity	Ethernet
Waveform Capture Rate	>50, 000 wfms/s
Trigger Types	Edge, Pulse Width, Logic, Setup/Hold, Rise/Fall Time, Video
Math Functions	FFT
Probe Interface	TekVPI
Power Requirements	100 to 240 V ±10%, 50/60 Hz
