Tektronix MSO4032 Demo Instruction Manual

Giving Demos of Advanced Tektronix 40 00 Features
7. If you do not want to hold the pan knob
while looking through the wave form,
use the play/pause feature. Pressing
the play/pause button will cause the
oscilloscope to scroll the waveform
automatically for you.
To show th is, pu sh the play/pau se button.
The waveform should start scro lling.
Play speed is adjusted by turning the
pan knob.
To p a n in the other direction, just turn
the pan knob the other way to slow the
zoom box down and have it change
direction.
To quickly jump to another portion of
the record and resume playing when
done, turn the pan knob all the way in
that direction. This is pan on top of
play/pause.
Push the play/pause button again
to stop when there is something
(anything) of interest on the screen.
32 Tektronix 4000 Oscilloscope Demo Instruction Manual
