Specifications
Table 10: Mecha
nical specifications
Characteristic Description
Dimensions Nominal, non-
rackmount:
Height: 229 mm (9.0 in), including feet: 272 mm (10.7 in), including vertical handle and feet
Width: 439 mm (17.3 in) from handle hub to handle hub
Depth:
137 mm (5.4 in) from feet to front of knobs
145 mm (5.7 in) from feet to front of front cover
Nominal, ra
ckmount (5U rack sizes):
Height: 218 mm (8.6 in)
Width: 488 m m (19.2 in) from outside of handle to outside of handle
Depth: 559 m
m (22.0 in) from outside of handle to back of slide
Weight
5.1kg(11.
3 l bs), stand-alone instrument, without front cover
8.7 k g (19.1 lbs), instrument with rackmount, without front cover
9.5 kg (21.0 lbs), when packaged for domestic shipment and without rackmount
Clearance Requirements The clearance requirement for adequate cooling is:
50.8 mm (2
in) on the left side (when looking at the front of the instrument) and on the
rear of the unit
MSO4000 and DPO4000 Series Specifications and Performance Verification 15
