Tektronix MSO4032 Technical Reference

Performance Verification
Delta Time Measurem ent Accuracy
50 ohm, Full BW RMS
Channel 1–4 (M
SO/DPO4104)
MSO/DPO = 4 ns/Div, Source freq = 240 MHz
MSO/DPO V /D iv Source V
pp
Test result High limit
5 mV 40 mV 118 ps
100 mV 800 mV 117 ps
500 mV 4 V 117 ps
1 V 4 V 122 ps
MSO/DPO = 40 ns/Div, Source freq = 24 MHz
1 mV 8 mV 456 ps
5 mV 40 mV 275 ps
100 mV 800 mV 234 ps
500 mV 4 V 233 ps
1 V 4 V 417 ps
MSO/DPO = 400 n s/D iv, Sou rce freq = 2.4 M Hz
1 mV 8 mV 4.42 ns
5mV 40mV 2.50ns
100 mV 800 mV 2.05 ns
500 mV 4 V 2.03 ns
1 V 4 V 4.01 ns
MSO/DPO = 4 μs/Div, Source freq = 240 kHz
1mV 8mV 44.2ns
5mV 40mV 25.0ns
100 mV 800 mV 20.5 ns
500 mV 4 V 20.3 ns
1V 4V 40.1ns
MSO/DPO = 40 μs/Div, Source freq = 24 kHz
1 mV 8 mV 442 ns
5 mV 40 mV 250 ns
100 mV 800 mV 205 ns
500 mV 4 V 203 ns
1 V 4 V 401 ns
MSO/DPO = 400 μs/Div, Source freq = 2.4 kHz
1 mV 8 mV 4.42 μs
5mV 40mV 2.50μs
100 mV 800 mV 2.05 μs
500 mV 4 V 2.03 μs
1V 4V 4.01μs
30 MSO4000 and DPO4000 Series Specifications and Performance Verification
