Tektronix MSO4032 Technical Reference

Performance Verification
Delta Time M eas
urement Accuracy
Channel 1–4 (MS
O/DPO4034)
MSO/DPO = 4 ns/Div, Source freq = 240 MHz
MSO/DPO V /D iv Source V
pp
Test result High limit
5 mV 40 mV 232 ps
100 mV 800 mV 231 ps
500 mV 4 V 231 ps
1 V 4 V 232 ps
MSO/DPO = 40 ns/Div, Source freq = 24 MHz
1 mV 8 mV 436 ps
5 mV 40 mV 284 ps
100 mV 800 mV 259 ps
500 mV 4 V 258 ps
1V 4V 321ps
MSO/DPO = 400 n s/D iv, Sou rce freq = 2.4 M Hz
1 mV 8 mV 3.72 ns
5mV 40mV 1.70ns
100 mV 800 mV 1.23 ns
500 mV 4 V 1.21 ns
1 V 4 V 2.26 ns
MSO/DPO = 4 μs/Div, Source freq = 240 kHz
1mV 8mV 37.0ns
5mV 40mV 16.5ns
100 mV 800 mV 11.6 ns
500 mV 4 V 11.4 ns
1V 4V 22.3ns
MSO/DPO = 40 μs/Div, Source freq = 24 kHz
1 mV 8 mV 370 ns
5 mV 40 mV 165 ns
100 mV 800 mV 116 ns
500 mV 4 V 114 ns
1 V 4 V 223 ns
MSO/DPO = 400 μs/Div, Source freq = 2.4 kHz
1 mV 8 mV 3.70 μs
5mV 40mV 1.65 μs
100 mV 800 mV 1.16 μs
500 mV 4 V 1.14 μs
1V 4V 2.23 μs
32 MSO4000 and DPO4000 Series Specifications and Performance Verification
