Tektronix MSO4034 Demo Instruction Manual

Giving Demos of M SO400 0 Features
Now let’s create a clocked bus.
8. Push Define Inputs from the lower-bezel
menu.
Bus B1
Parallel
Define
Inputs
Thresholds B1 Label Bus Display Event Table
Define
Inputs
9. Push the side-bezel Clocked Data button to
select Yes.
Clocked
Data
Yes|No
10. Confirm that the side-bezel Clock Edge button
is set to the rising edge icon.
Clock Edge
11. Confirm that the side-menu Number of Data
Bits b utton is still set to 7.
Number of
Data Bits
7
12. Push the side-menu Define Bits butto n (if not
already active). Confirm that the source type
is set to Clock.Ifnot,turna to select it. Turn
multipurpose knob b to select D7 as the c lock
source.
Define Bits
aClock
bD7
82 Tektronix 4000 Oscilloscope Demo Instruction Manual
