Tektronix MSO4034 Technical Reference

Performance Verification
DC Offset Accuracy
Performance
checks Vertical scal
e
Vertical offs
et
1
Low limit Test result
High limit
DPO4104, DPO4054, DPO4034, MSO4104, MSO4054, MSO4034:
1 m V/div
900 mV 895.0 mV 905.0 mV
1 m V/div
-900 mV -905.0 mV -895.0 mV
2 m V/div
500 mV 497.0 mV 503.0 mV
2 m V/div
-500 mV -503.0 mV -497.0 mV
10 mV/div
500 mV 495.5 mV 504.5 mV
10 mV/div
-500 mV -504.5 mV -495.5 mV
100 mV/div
5.0 V 4.955 V 5.045 V
Channel 3 DC O ffset
Accuracy,
20 MHz BW, 50 Ω
100 mV/div
-5.0 V -5.04.5 V -4.955 V
1 m V/div
900 mV 895.2 mV 904.8 mV
1 m V/div
-900 mV -904.8 mV -895.2 mV
2 m V/div
500 mV 497.1 mV 502.9 mV
2 m V/div
-500 mV -502.9 mV -497.1 mV
10 mV/div
500 mV 495.5 mV 504.5 mV
10 mV/div
-500 mV -504.5 mV -495.5 mV
100 mV/div
5.0 V 4.955 V 5.045 V
100 mV/div
-5.0 V -5.045 V -4.955 V
1.01 V/div
99.5 V 98.80 V 100.2 V
Channel 3 DC O ffset
Accuracy,
20 MHz BW, 1 MΩ
1.01 V/div
-99.5 V -100.2 V -98.80 V
1 m V/div
900 mV 895.0 mV 905.0 mV
1 m V/div
-900 mV -905.0 mV -895.0 mV
2 m V/div
500 mV 497.0 mV 503.0 mV
2 m V/div
-500 mV -503.0 mV -497.0 mV
10 mV/div
500 mV 495.5 mV 504.5 mV
10 mV/div
-500 mV -504.5 mV -495.5 mV
100 mV/div
5.0 V 4.955 V 5.045 V
Channel 4 DC O ffset
Accurac
y,
20 MHz BW, 50 Ω
100 mV/div
-5.0 V -5.045 V -4.955 V
MSO4000 and DPO4000 Series Specifications and Performance Verification 27
