Tektronix MSO4054 Technical Reference

Performance Verification
DC Gain Accuracy
Performance checks Vertical scale Low limit Test result High limit
1 mV/div -1.5% 1.5%
2 mV/div -1.5% 1.5%
4.98 m V /div -3.0% 3.0%
5 mV/div -1.5% 1.5%
10 m V/div -1.5% 1.5%
20 m V/div -1.5% 1.5%
49.8 mV
-3.0% 3.0%
50 m V/div -1.5% 1.5%
100 m V /div -1.5% 1.5%
200 m V /div -1.5% 1.5%
500 m V /div -1.5% 1.5%
Channel 3 DC Gain
Accuracy, 0 V offset,
0Vverticalp
osition,
20 MHz BW, 1 MΩ
1 V/div -1.5% 1.5%
1 mV/div -1.5% 1.5%
2 mV/div -1.5% 1.5%
4.9
8mV
-3.0% 3.0%
5 mV/div -1.5% 1.5%
10 m V/div -1.5% 1.5%
20 m V/div -1.5% 1.5%
4
9.8 mV
-3.0% 3.0%
50 m V/div -1.5% 1.5%
100 m V /div -1.5% 1.5%
200 m V /div -1.5% 1.5%
500 m V /div -1.5% 1.5%
Channel 4 DC Gain
Accuracy, 0 V offset,
0Vv
ertical position,
20 MHz BW, 50 Ω
1.0 V/div -1.5% 1.5%
1 mV/div -1.5% 1.5%
2 mV/div -1.5% 1.5%
4.98 m V /div -3.0% 3.0%
5 mV/div -1.5% 1.5%
10 m V/div -1.5% 1.5%
20 m V/div -1.5% 1.5%
49.8 mV
-3.0% 3.0%
50 m V/div -1.5% 1.5%
100 m V /div -1.5% 1.5%
200 m V /div -1.5% 1.5%
500 m V /div -1.5% 1.5%
Channel 4 DC Gain
Accuracy, 0 V offset,
0 V vertical position,
20 MHz BW, 1 MΩ
1 V/div -1.5% 1.5%
MSO4000 and DPO4000 Series Specifications and Performance Verification 25
