Specifications
Table 1: Analog channel input and vertical specifications (cont.)
Characteristic Description
These l imits are for ambient temperature of 30°C and the bandwidth selection set to FULL. Reduce the
upper bandwidth frequency by 1% for each °C above 30°C
Instrument
Volts/Div setting
Bandwidth
50 mV/div — 100 V/div DC to 1 GHz (TPP1000
probe)
DC to 500 MHz
(TPP0500 probe)
20 mV/div — 49.8 mV/div DC to 350 MHz
MSO4104B,
DPO4104B,
MSO4104B-L,
DPO4104B-L,
MSO4102B-L,
DPO4102B-L,
MSO4102B,
DPO4102B
10 mV/div — 19.9 mV/div DC to 175 MHz
50 mV/div — 100 V/div DC to 500 MHz
20 mV/div — 49.8 mV/div DC to 350 MHz
DPO4054B
10 mV/div — 19.9 mV/div DC to 175 MHz
50 mV/div — 100 V/div DC to 350 MHz
20 mV/div — 49.8 mV/div DC to 350 MHz
DPO4034B
10 mV/div — 19.9 mV/div DC to 175 MHz
Analog bandwidth with
TPP0500 or TP P1000
probe, typical
DPO4014B 10 mV/div — 100 V/div DC to 100 MHz
Lower frequency limit,
AC coupled, typical
< 10 Hz when AC, 1 M coupled
The AC coupled lower frequency limits are reduced by a factor of 10 when 10X passive probes are used.
Upper frequency limit,
250 MHz bandwidth
limited, typical
250 MHz, ±20%
Not available on the DPO4014B
Upper frequency limit,
20 MHz bandwidth
limited, typical
20 MHz, ±20%
6 MSO4000B and DPO4000B Series Specifications and Performance Verifi cation
