Tektronix MSO4104B Technical Reference

Performance Verification
Delta Time Meas
urement Accu racy
All four-chan
nel a nd 1 GHz models
(MSO4104B, DPO4104B, MSO4104B-L, and DPO4104B-L)
Channel 4
MSO/DPO = 4 ns/Div, Source freq = 240 MHz
MSO/DPO V/Div Source V
pp
Test result High limit
5mV 40mV 118ps
100 mV 800 mV 117 ps
500 mV 4 V 117 ps
1 V 4 V 122 ps
MSO/DPO =
40 ns/Div, Source freq = 24 MH z
1 mV 8 mV 464 ps
5 mV 40 mV 276 ps
100 mV 800 mV 234 ps
500 mV 4 V 232 ps
1 V 4 V 417 ps
MSO/DPO = 400 ns/Div, Source freq = 2.4 MHz
1 mV 8 mV 4.50 n
s
5mV 40mV 2.52ns
100 mV 800 mV 2.05 ns
500 m
V
4 V 2.03
ns
1 V 4 V 4.01 ns
MSO/DPO = 4 μs/Div, Source freq = 240 kHz
1 mV 8 mV 45.0 ns
5m
V
40
mV
25
.2 ns
100 mV 800 mV 20.5 ns
500 mV 4 V 20.3 ns
1
V
4
V
4
0.1 ns
M
SO/DPO = 40 μs/Div, Source freq = 24 kHz
1 mV 8 mV 450 ns
5 mV 40 mV 252 ns
100 mV 800 mV 205 ns
500 mV 4 V 203 ns
1 V 4 V 401 ns
MSO/DPO = 400 μs/Div, Source freq = 2.4 kHz
1 mV 8 mV 4.50 s
5mV 40mV 2.52s
100 mV 800 mV 2.05 s
500 mV 4 V 2.03 s
1 V 4 V 4.01 s
MSO4000B and DPO4000B Series Specifications and Performance Verification 47
