Tektronix MSO44 Declassification And Security Instructions

Media and data export devices
The following table lists the data export devices in the instrument.
Type Function Method of
modification
Data input method Location User accessible
USB Host ports User storage and
recall of reference
waveforms, screen
images, and
instrument setups,
and installation of
firmware updates
using removable USB
flash drives
Directly User writeable Three USB Host
ports on front of the
instrument; two USB
Host ports on the
back of the
instrument
Yes
USB Device port Remote control and
data transfer to a PC
Directly Remote control using
USBTMC
USB Device port on
back of the
instrument
Yes
Ethernet Transfer data and
remote control of
instrument.
Directly Remote control using
LXI, VISA, or Socket
Server
Ethernet port on back
of instrument
Yes
Clear and sanitize procedures
10

Tektronix MSO44 Specifications

General

Bandwidth	200 MHz, 350 MHz, 500 MHz, 1 GHz
Analog Channels	4
Operating Temperature	0 °C to +50 °C
Sample Rate	6.25 GS/s
Record Length	62.5 Mpoints
Input Impedance	1 MΩ ±1%, 50 Ω ±1%
Vertical Resolution	12 bits
Waveform Capture Rate	Up to 500, 000 wfm/s
Maximum Input Voltage	5 VRMS (50 Ω)
Probe Interface	TekVPI
Digital Channels	16 (optional)
