Data storage specifications
Nonvolatile memory retention time,
typical
No time limit for front-panel settings, saved waveforms, setups, and calibration constants
Real-time clock A programmable clock providing time in years, months, days, hours, minutes, and seconds
Hard disk drive (standard for MSO/
DPO5000 Series)
The 2.5-inch SATA hard disk drive capacity is ≥160 GB. Waveforms and setups are stored on the
hard disk.
Solid state disk drive (standard for
MSO/DPO5000B Series, optional
for MSO/DPO5000 Series)
The 2.5-inch solid state disk drive capacity is ≥300 GB. Waveforms and setups are stored on the
solid state disk.
Power source specifications
Source voltage 100 V to 240 V ±10%
Source frequency (85 to 264 V) 45 Hz to 66 Hz
(100 V to 132 V) 360 Hz to 440 Hz
Fuse rating T6.3AH, 250 V
ac
The fuse cannot be replaced by the user.
Specifications (MSO/DPO5000/B Series)
96 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
