Tektronix MSO70000C/DX

DC voltage measurement accuracy (averaged), >20 GHz models
Instrument performance test Minimum Incoming Outgoing Maximum
Ch1 100 mV Vert scale setting, 0 Div position setting
+3.5 V termination
+3.4 V offset
+2.4 V offset
+1.5 V termination
+2.5 V offset
+1.5 V offset
+0.5 V offset
0 V termination
0 V offset
-1 V offset
+1 V offset
-3.5 V termination
-3.4 V offset
-2.4 V offset
-1.5 V termination
-2.5 V offset
-1.5 V offset
-0.5 V offset
3.6637 V
2.6657 V
2.7655 V
1.7715 V
773.5 mV
277.5 mV
-728.5 mV
1.2715 V
-3.7363 V
-2.7343 V
-2.8345 V
-1.8285 V
-826.5 mV
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
3.7363 V
2.7343 V
2.8345 V
1.8285 V
826.5 mV
322.5 mV
-671.5 mV
1.3285 V
-3.6637 V
-2.6657 V
-2.7655 V
-1.7715 V
-773.5 mV
Ch1 120 mV Vert scale setting, 0 Div position setting
+3.5 V termination
+3.4 V offset
+2.4 V offset
+1.5 V termination
+2.5 V offset
+1.5 V offset
+0.5 V offset
0 V termination
0 V offset
-1 V offset
+1 V offset
-3.5 V termination
-3.4 V offset
-2.4 V offset
-1.5 V termination
-2.5 V offset
-1.5 V offset
-0.5 V offset
3.7197 V
2.7217 V
2.8215 V
1.8275 V
829.5 mV
333.5 mV
-672.5 mV
1.3275 V
-3.8003 V
-2.7983 V
-2.8985 V
-1.8925 V
-890.5 mV
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
3.8003 V
2.7983 V
2.8985 V
1.8925 V
890.5 mV
386.5 mV
-607.5 mV
1.3925 V
-3.7197 V
-2.7217 V
-2.8215 V
-1.8275 V
-829.5 mV
Ch1 140 mV Vert scale setting, 0 Div position setting
0 V termination
–1 V offset
0 V offset
+1 V offset
-624.5 mV
379.5 mV
1.3755 V
__________
__________
__________
__________
__________
__________
-535.5 mV
460.5 mV
1.4645 V
Ch1 200 mV Vert scale setting, 0 Div position setting
0 V termination
–1 V offset
0 V offset
+1 V offset
-456.5 mV
547.5 mV
1.5435 V
__________
__________
__________
__________
__________
__________
-343.5 mV
652.5 mV
1.6565 V
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
124 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
