DC voltage measurement accuracy (averaged), >20 GHz models
Instrument performance test Minimum Incoming Outgoing Maximum
Ch3 20 mV Vert scale setting, 0 Div position setting
+3.5 V termination
+3.4 V offset
+2.4 V offset
+1.5 V termination
+2.5 V offset
+1.5 V offset
+0.5 V offset
0 V termination
0 V offset
-1 V offset
+1 V offset
-3.5 V termination
-3.4 V offset
-2.4 V offset
-1.5 V termination
-2.5 V offset
-1.5 V offset
-0.5 V offset
3.4397 V
2.4417 V
2.5415 V
1.5475 V
549.5 mV
53.5 mV
-952.5 mV
1.0475 V
-3.4803 V
-2.47831 V
-2.5785 V
-1.5725 V
-570.5 mV
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
3.4803 V
2.4783 V
2.5785 V
1.5725 V
570.5 mV
66.5 mV
-927.5 mV
1.0725 V
-3.4397 V
-2.4417 V
-2.5415 V
-1.5475 V
-549.5 mV
Ch3 50 mV Vert scale setting, 0 Div position setting
+3.5 V termination
+3.4 V offset
+2.4 V offset
+1.5 V termination
+2.5 V offset
+1.5 V offset
+0.5 V offset
0 V termination
0 V offset
-1 V offset
+1 V offset
-3.5 V termination
-3.4 V offset
-2.4 V offset
-1.5 V termination
-2.5 V offset
-1.5 V offset
-0.5 V offset
3.5237 V
2.5257 V
2.6255 V
1.6315 V
633.5 mV
137.5 mV
-868.5 mV
1.1315 V
-3.5763 V
-2.5743 V
-2.6745 V
-1.6685 V
-666.5 mV
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
3.5763 V
2.5743 V
2.6745 V
1.6685 V
666.5 mV
162.5 mV
-831.5 mV
1.1685 V
-3.5237 V
-2.5257 V
-2.6255 V
-1.6315 V
-633.5 mV
