Tektronix MSO70000C/DX

DC voltage measurement accuracy (averaged), <4 GHz models, 50 Ω
Instrument performance test Minimum Incoming Outgoing Maximum
Ch2 10 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 585.81 mV __________ __________ - 574.19 mV
Ch2 20 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 651.62 mV __________ __________ + 668.38 mV
Ch2 20 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 668.38 mV __________ __________ - 651.62 mV
Ch2 50 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 883.81 mV __________ __________ + 916.19 mV
Ch2 50 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 916.19 V __________ __________ - 883.81 mV
Ch2 90 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 1.192 V __________ __________ + 1.248 V
Ch2 90 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 1.248 V __________ __________ - 1.192 V
Ch2 100 mV Vert scale setting,
0 Div position setting, +4.5 V offset
+ 4.746 V __________ __________ + 4.854 V
Ch2 100 mV Vert scale setting,
0 Div position setting, -4.5 V offset
- 4.854 V __________ __________ - 4.746 V
Ch2 200 mV Vert scale setting,
-2 Div position setting, +4.6 V offset
+ 4.725 V __________ __________ + 4.875 V
Ch2 200 mV Vert scale setting,
+2 Div position setting, -4.6 V offset
- 4.875 V __________ __________ - 4.725 V
Ch2 500 mV Vert scale setting,
-2 Div position setting, +5.0 V offset
+ 4.345 V __________ __________ + 4.655 V
Ch2 500 mV Vert scale setting,
+2 Div position setting, -5.0 V offset
- 4.655 V __________ __________ - 4.345 V
Ch2 1.0 V Vert scale setting,
0 Div position setting, +2.0 V offset
+ 4.742 V __________ __________ + 5.258 V
Ch2 1.0 V Vert scale setting,
0 Div position setting, -2.0 V offset
- 5.258 V __________ __________ - 4.742 V
Ch3 1 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 504.24 mV __________ __________ + 509.76 mV
Ch3 1 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 509.76 mV __________ __________ - 504.24 mV
Ch3 2 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 512.97 mV __________ __________ + 519.03 mV
Ch3 2 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 519.03 mV __________ __________ - 512.97 mV
Ch3 5 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 536.26 mV __________ __________ + 543.74 mV
Ch3 5 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 543.74 mV __________ __________ - 536.26 mV
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
138 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
